Audio and speaker cable

GL-2CS100 & GL-2CSA100

Audio and Speaker Cables

Features

Speaker Cable : GL-2CS100

16 AWG(65/34 AWG), bare copper conductor, PVC insulated, 2 conductor laid, PVC jacketed Speaker Cable

Audio Cable : GL-2CSA100

20 AWG (10/30 AWG), tinned copper conductor, PVC insulated, 2 conductor cabled Screened with Aluminium mylar tape with tinned copper drain wire(10×30 AWG), PVC jacketed Audio Cable

Specifications

GL-2CS100

  • Conductor Annealed bare Copper Conductor EC Grade IS:8130
  • Number of Wires 65 Nos
  • Overall Diameter (nominal) 2.6
  • Material PVC
  • Diameter 6.50 mm (Nom)
  • Outer Sheath Colour Dark Grey

GL-2CSA100

  • Conductor Annealed bare Copper Conductor EC Grade IS:8130
  • Number of Wires 10 Nos
  • Overall Diameter (nominal) 1.8
  • Material PVC
  • Diameter 5.50 mm (Max)
  • Outer Sheath Colour Dark Grey
