Flex Series
  • Features
  • Specifications
  • Resources

Features

Eye-Catching Architectural Design

Our durable and corrosion-resistant design ensures that our displays will last for years to come. With better heat dissipation, you can rest assured that the Aura Series will remain reliable even in high-stress environments.

Specifications

  • MODEL NAMELF-I12
  • ApplicationIndoor
  • Pixel Pitch (in mm)1.2
  • LED TypeSMD
  • LED Lifetime (In Hours)100,000
  • Brightness (cd/m²)≥600
  • Contrast Ratio5000:1
  • Frame Rate (Hz)60
  • Refresh Rate (Hz)3840
  • Model Dimension W x H (in mm)320×160
  • Model Resolution (WxH)256×128
  • Weight (g/module)315
  • Service AccessFront
  • Optimal Viewing Angle (H/V)160°/140°
  • Storage Temperature20°C~60°C
  • Working Temperature-10°C~50°C
  • Relative Humidity20~85%
  • Storage Humidity20~80%
  • VoltageAC 110-220 V
  • Power Consumption (Avg) (in W/m²)252
  • Power Consumption (Max) (in W/m²)766
  • MTBF (in Hours)80000
  • IP Rating (Front/Rear)IP40
  • Grey Scale16
  • MODEL NAMELF-I15
  • ApplicationIndoor
  • Pixel Pitch (in mm)1.5
  • LED TypeSMD
  • LED Lifetime (In Hours)100,000
  • Brightness (cd/m²)≥600
  • Contrast Ratio5000:1
  • Frame Rate (Hz)60
  • Refresh Rate (Hz)3840
  • Model Dimension W x H (in mm)320×160
  • Model Resolution (WxH)209×104
  • Weight (g/module)301
  • Service AccessFront
  • Optimal Viewing Angle (H/V)160°/140°
  • Storage Temperature20°C~60°C
  • Working Temperature-10°C~50°C
  • Relative Humidity20~85%
  • Storage Humidity20~80%
  • VoltageAC 110-220 V
  • Power Consumption (Avg) (in W/m²)698
  • Power Consumption (Max) (in W/m²)202
  • MTBF (in Hours)80000
  • IP Rating (Front/Rear)IP40
  • Grey Scale16
  • MODEL NAMELF-I18
  • ApplicationIndoor
  • Pixel Pitch (in mm)1.8
  • LED TypeSMD
  • LED Lifetime (In Hours)100,000
  • Brightness (cd/m²)≥650
  • Contrast Ratio5000:1
  • Frame Rate (Hz)60
  • Refresh Rate (Hz)3840
  • Model Dimension W x H (in mm)320×160
  • Model Resolution (WxH)172×86
  • Weight (g/module)228
  • Service AccessFront
  • Optimal Viewing Angle (H/V)160°/140°
  • Storage Temperature20°C~60°C
  • Working Temperature-10°C~50°C
  • Relative Humidity20~85%
  • Storage Humidity20~80%
  • VoltageAC 110-220 V
  • Power Consumption (Avg) (in W/m²)589
  • Power Consumption (Max) (in W/m²)186
  • MTBF (in Hours)80000
  • IP Rating (Front/Rear)IP40
  • Grey Scale16
  • MODEL NAMELF-I20
  • ApplicationIndoor
  • Pixel Pitch (in mm)2
  • LED TypeSMD
  • LED Lifetime (In Hours)100,000
  • Brightness (cd/m²)≥750
  • Contrast Ratio5000:1
  • Frame Rate (Hz)60
  • Refresh Rate (Hz)3840
  • Model Dimension W x H (in mm)320×160
  • Model Resolution (WxH)160×80
  • Weight (g/module)315
  • Service AccessFront
  • Optimal Viewing Angle (H/V)160°/140°
  • Storage Temperature20°C~60°C
  • Working Temperature-10°C~50°C
  • Relative Humidity20~85%
  • Storage Humidity20~80%
  • VoltageAC 110-220 V
  • Power Consumption (Avg) (in W/m²)600
  • Power Consumption (Max) (in W/m²)200
  • MTBF (in Hours)80000
  • IP Rating (Front/Rear)IP40
  • Grey Scale16
  • MODEL NAMELF-I25
  • ApplicationIndoor
  • Pixel Pitch (in mm)2.5
  • LED TypeSMD
  • LED Lifetime (In Hours)100,000
  • Brightness (cd/m²)≥750
  • Contrast Ratio5000:1
  • Frame Rate (Hz)60
  • Refresh Rate (Hz)3840
  • Model Dimension W x H (in mm)320×160
  • Model Resolution (WxH)128×64
  • Weight (g/module)220
  • Service AccessFront
  • Optimal Viewing Angle (H/V)160°/140°
  • Storage Temperature20°C~60°C
  • Working Temperature-10°C~50°C
  • Relative Humidity20~85%
  • Storage Humidity20~80%
  • VoltageAC 110-220 V
  • Power Consumption (Avg) (in W/m²)600
  • Power Consumption (Max) (in W/m²)200
  • MTBF (in Hours)80000
  • IP Rating (Front/Rear)IP40
  • Grey Scale16

Resources

Download Datasheet
