Optix Series
  • Features
  • Specifications
  • Resources

Features

Eye-Catching Architectural Design

Our durable and corrosion-resistant design ensures that our displays will last for years to come. With better heat dissipation, you can rest assured that the Aura Series will remain reliable even in high-stress environments.

Specifications

  • ApplicationIndoor
  • Pixel Pitch (in mm)3.91mm
  • LED TypeSMD
  • LED Lifetime (In Hours)100000
  • Brightness (cd/m²)5000
  • Contrast Ratio5000:1
  • Frame Rate (Hz/sec)60
  • Refresh Rate (Hz/sec)≥3840
  • Panel Dimension W x H x D (in mm)1000x250x3
  • Physical Resolution256x64
  • Weight (Kg/Cabinet)2.5
  • Service AccessRear
  • Optimal Viewing Angle (H/V)140 /160
  • Storage Temperature﹣20~﹢50
  • Working Temperature﹣20~﹢60
  • VoltageAC : 100~240V 50/60Hz
  • Power Consumption (Avg) (in W/m²)240
  • Power Consumption (Max) (in W/m²)800
  • Protection LevelIP43
  • Grey Scale14bit
  • Physical Density65536
  • ApplicationIndoor
  • Pixel Pitch (in mm)6.25mm
  • LED TypeSMD
  • LED Lifetime (In Hours)100000
  • Brightness (cd/m²)5000
  • Contrast Ratio5000:1
  • Frame Rate (Hz/sec)60
  • Refresh Rate (Hz/sec)≥3840
  • Panel Dimension W x H x D (in mm)1000x250x3
  • Physical Resolution16x40
  • Weight (Kg/Cabinet)2.5
  • Service AccessRear
  • Optimal Viewing Angle (H/V)140 /160
  • Storage Temperature﹣20~﹢50
  • Working Temperature﹣20~﹢60
  • VoltageAC : 100~240V 50/60Hz
  • Power Consumption (Avg) (in W/m²)240
  • Power Consumption (Max) (in W/m²)800
  • Protection LevelIP43
  • Grey Scale14bit
  • Physical Density25600
  • ApplicationIndoor
  • Pixel Pitch (in mm)10mm
  • LED TypeSMD
  • LED Lifetime (In Hours)100000
  • Brightness (cd/m²)5000
  • Contrast Ratio5000:1
  • Frame Rate (Hz/sec)60
  • Refresh Rate (Hz/sec)≥3840
  • Panel Dimension W x H x D (in mm)1000x250x3
  • Physical Resolution100x25
  • Weight (Kg/Cabinet)2.5
  • Service AccessRear
  • Optimal Viewing Angle (H/V)140 /160
  • Storage Temperature﹣20~﹢50
  • Working Temperature﹣20~﹢60
  • VoltageAC : 100~240V 50/60Hz
  • Power Consumption (Avg) (in W/m²)240
  • Power Consumption (Max) (in W/m²)800
  • Protection LevelIP43
  • Grey Scale14bit
  • Physical Density10000
  • ApplicationIndoor
  • Pixel Pitch (in mm)15.6mm
  • LED TypeSMD
  • LED Lifetime (In Hours)100000
  • Brightness (cd/m²)5000
  • Contrast Ratio5000:1
  • Frame Rate (Hz/sec)60
  • Refresh Rate (Hz/sec)≥3840
  • Panel Dimension W x H x D (in mm)1000x250x3
  • Physical Resolution64x16
  • Weight (Kg/Cabinet)2.5
  • Service AccessRear
  • Optimal Viewing Angle (H/V)140 /160
  • Storage Temperature﹣20~﹢50
  • Working Temperature﹣20~﹢60
  • VoltageAC : 100~240V 50/60Hz
  • Power Consumption (Avg) (in W/m²)240
  • Power Consumption (Max) (in W/m²)800
  • Protection LevelIP43
  • Grey Scale14bit
  • Physical Density4096

Resources

Download Datasheet
